Exmark Lazer Z Series User Manual

Schematics
HydraulicDiagram—96InchModels
S1
X T P
0.020”
0.020”
C B A
WINGFOLD CYLINDER
1.25” BORE X 0.75” ROD X 3.5” STROKE
LIFT
CYLINDER
3/4” x 6.9”
3.04 in disp.
3
.040
4000 PSI
0.031 in
17.8 CID
T
OW
VALVE
1.1 CID
GEARBOX
1.1
CI
D
PTO CLUTCH
PTO
PRE
SS
URE
TEST PO
R
T
4000 PSI
0.031 in
1
7.
8
CI
D
TOW V
A
L
V
E
0.37 CID0.37 CID
PORT 1
Suc
t
ion
S
creen
100 Mesh
Charge Pum
p
G
e
ar
Pump
3000 PSI
Line Filter Beta 11 = 200(ISO 16889)
43 PSI
CHARGE RELIEF
86+/-15 PSI
CH
ARGE
PR
ESS
URE
T
E
ST
POR
T
PRESSURE VALVE 313+/-30 PSI
OIL COOLER
1:0.691
1
:1
1:1.025 1:1.025
PORT 2
0.031 in
YANMAR 3TNV88C 3000/1400 RPM
IMPLEMENT RELIEF
g239212
73

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
