Section 6
Weight and Balance and Equipment List
PilotĀ“s Operating Handbook
EXTRA 300L
1 Starter B&C Speciality BC 315-100-2 4.63 -0.85 R
1 Starter SKYTEC 149-12LS 3.65 -0.85 A
(Lycoming) (31A22 104)
1 Alternator 60 Amps Electrosystems ALX 8421 LS 5.90 -0.86 R
with bracket
1 Voltage Regul. Lamar B-00371-25 0.15 0.02 R
1 Low Volt. Monitor Lamar B-00378-4 R
1 Alternator 65 Amps Bosch 0 120 489 935 4.60 -0.86 A
1 Alternator 55 Amps Bosch 0 120 489 917 4.20 -0.86 A
1 Alternator 55 Amps Bosch 0 120 489 469 4.20 -0.86 A
1 Alternator 65 Amps Prestolite 66021637 4.70 -0.86 A
1 Battery Sonnenschein Dryfit A 212/28G 10.70 0.23 R
1 Battery Concorde RG-25XC 10.40 0.23 A
1 Batt. Charger Plug EXTRA 146 19 20 0.02 0.17 O
1 Ext. Power Recept. Div. AN2552-3A 1.46 1.07 O
1 Ext. Power Solenoid Switches Kidde 22735 0.40 0.03 O
1 Ext. Power Solenoid White-Rodgers 70-111-225-5 0.40 0.03 O
(cont. operation)
1 Main Bus Solenoid White-Rodgers 70-111-226-5 0.40 0.03 R
1 Starter Solenoid Switches Kidde 22735 0.40 0.03 R
1 Low Voltage Light OAK MS25041-2 0.02 1.63 R
1 Starter Engaged Light OAK MS25041-4 0.02 1.63 O
1 Ignition Switch TCM 10-357200-1 0.15 1.63 R
2 Wheel Cleveland 40-151 4.00 0.33 R
2 Main Wheel Tires Div 5.00-5 / 6PR 3.90 0.33 R
1 Tail Wheel 5" EXTRA steerable 5.50 5.23 R
1 Tail Wheel 6" Assy Special Products 5.90 5.23 A
(Soft) Aviation Inc.
2 Brake Assy Cleveland 30-164 1.40 0.33 R
2 Brake Cyl., front Cleveland 10-20 or 10-20E 0.55 0.15 R
2 Brake Cyl., front Matco MC-4E 0.55 0.15 A
2 Brake Cyl., rear Cleveland 10-20 or 10-20E 0.55 1.15 R
2 Brake Cyl., rear Matco MC-4E 0.55 1.15 A
1 Brake Fluid Reservoir EXTRA 53301.1 0.20 0.03 R
1 Brake Fluid Reservoir ACS A-315 0.20 0.04 A
1 Safety Belt Assy Hooker FK0002 or FK0019 3.30 2.12 R
Rear Seat (1011230 [3x] &
(seat belts w. ratchet, 1113012-1 [1x],
shoulder harness, 1H5630-3 [2x]
crotch strap) 1CS924-D or -N [1x])
1 Safety Belt Assy Hooker 1011230 [4x], 2.90 1.03 R
Front Seat 1H3030-3 [2x]
(seat belts, 1CS924-D or -N [1x]
shoulder harness,
crotch strap)
QTY ITEM MANUFACT. PART OR P/N WEIGHT ARM MARK IF REQUIRED (R)
(kg) (m) INSTALLED OPTIONAL (O)
ALTERNAT. (A)
