6 - 16 Page Date: 20. April 2002
Section 6
Weight and Balance and Equipment List
PilotĀ“s Operating Handbook
EXTRA 300L
1 Safety Belt Assy Hooker FK0004 or FK0020 3.30 1.03 A
Front Seat (1011230 [3x] &
(seat belts w. ratchet, 1113012-1 [1x],
shoulder harness, 1H3030-3 [2x]
crotch strap) 1CS924-D or -N [1x])
2 NAV/STROBE LTS Whelen A 600-PG/PR-14 0.23 0.74 R
2 Power Supply Whelen A490T 0.54 0.74 R
1 Landing Light LED Whelen 01-71125-12 0.16 -0.57 O
1 Standard Canopy EXTRA 26301.000-LV 13.50 1.69 R
1 Single Seat EXTRA 86411.011-LV 13.20 1.69 A
Canopy
2 Electric Actuator SKF CARR 3.25 0.95 R
Pedal Adjust. 22x200x1/D12B
1 Long Range Tank EXTRA 86901 1.80 0.55 O
1 Center Tank 42 L EXTRA 66203.001-LK 3.30 0.30 R
1 Center Tank 60 L EXTRA 86713.010-LK 3.90 0.30 A
1 Fuel Selector Allen 6 S 122 0.19 0.73 R
1 Safety Cover EXTRA 86803.1 1.68 3.03 O
(Polycarbonate)
1 Dual Pump EXTRA 86100 8.80 0,16 O
Smoke System
without Pumps
2 Smoke Oil Pump ITT Jabsco 8860-1203 3.60 0.10 O
(Inject. and Refill)
2 Smoke Oil Pump ITT Jabsco 23620-3003 4.40 0.10 O
(Inject. and Refill)
1 Smoke Oil Pump Johnson F3B-19 (12V) 2.00 -0.05 O
(Injection)
1 Smoke Oil Pump Johnson F2P10-19 (12V) 1.65 0.25 O
(Refill)
1 Single Pump EXTRA 86112 9.20 0.30 O
Smoke System
incl. Pump Marco UP3/OIL 12V
1 Airtow Hook EXTRA/TOST 83607A0 0.50 5.42 O
1/2 Sighting Dev. LH/RH EXTRA 83801.10 each 0.54 1.59 O
1 Aresti-Card Holder EXTRA Assy 0.09 1.66 O
2 Wing Tie Down Rings EXTRA 83801.2-01 0.04 1.08 O
1 Remote Mounted Airwolf Filter Corp. AFC-K007 -0.09 O
Oil Filter Kit
QTY ITEM MANUFACT. PART OR P/N WEIGHT ARM MARK IF REQUIRED (R)
(kg) (m) INSTALLED OPTIONAL (O)
ALTERNAT. (A)
