DXP HD 4K PLUS Series • SIS Configuration and Control 59
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Information Requests (continued)
View detailed firmware version
information
0Q
X2%-X2^
1
-X2^
2
]
View the boot loader, factory,
and current user firmware
versions.
X2% = boot loader version
X2^
1
= factory base firmware
X2^
2
= updated firmware
NOTE: For X2^, the following symbols may appear after the version number (see the example below):
• * = The firmware version is the current or active version.
• ?.?? = Only the factory firmware version is loaded. This replaces the updated firmware version.
• ^ = The default factory firmware version is loaded instead of the listed version due to a mode 1 reset.
• ! = The current firmware version is corrupted.
Example response:
1.00-1.00.0000-b001(1.81LX-DXP-HD -Thu, 01 Jan 2015 00:01 UTC)-1.00.0000-b004*(1.91LX-DXP-HD -Mon, 16 Nov 2015 10:26 UTC)
]
boot
loader
version
factory base firmware version updated firmware version
version
number
kernel
version
model
description
upload date
and time
indicator
View matrix status
S
X2&
•
X2*
•
X2(]
Sts00*X2&
•
X2*
•
X2(]
View the power supply
voltage, temperature, and fan
speed status.
Verbose modes 2 and 3
View power supply status
1S
X2&]
Sts01*X2&]
View the power supply
voltage.
Verbose modes 2 and 3
View temperature
2S
X2*]
Sts02*X2*]
View the internal temperature.
Verbose modes 2 and 3
View fan speed
3S
X2(]
Sts03*X2(]
View the internal fan speed.
Verbose modes 2 and 3
KEY:
X2% = Firmware version
n.nn
X2^ = Verbose firmware version
[version]([kernel]-[description]-[upload date and
time])
X2& = Power supply
In volts
X2* = Temperature
In degrees Celsius
X2( = Fan
In RPM
