DXP HD 4K PLUS Series • SIS Configuration and Control 60
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
IP Control Port Commands
IP Setup
Set DHCP mode
24
EX#DH} IdhX#]
Enable or disable DHCP.
View DHCP mode
EDH} X#]
View the DHCP mode setting.
Set IP address
24
EX2*CI} Ipi
•
X3)]
Set the IP address.
View IP address
ECI} X3)]
View the current IP address.
Set subnet mask
24
EX3!CS} Ips
•
X3!]
Set the subnet mask.
View subnet mask
ECS} X3!]
View the subnet mask setting.
Set gateway IP address
24
EX3@CG} Ipg
•
X3@]
Set the gateway IP address.
View gateway IP address
ECG} X3@]
View the gateway IP address.
View MAC address
ECH} X3#]
Iph
•
X3#]
00-05-A6-xx-xx-xx
Verbose modes 2 and 3
View number of open
connections
ECC} X3$]
IccX3$]
View the number of open
connections.
Verbose modes 2 and 3
Port Timeout
Set current port timeout
E0*X3%TC} Pti0*X3%]
Set the duration of inactivity
required to automatically
terminate a connection on the
current port.
View current port timeout
E0TC} X3%]
Pti0*X3%]
View the duration of inactivity
required to automatically
terminate a connection on the
current port.
Set global IP port timeout
E1*X3%TC} Pti1*X3%]
Set the initial timeout value for
any connection.
View global IP port timeout
E1TC} X3%]
Pti1*X3%]
View the initial timeout value
for any connection.
KEY:
X# = Enable or disable
0 = disable, 1 = enable
X3) = IP address
nnn.nnn.nnn.nnn (192.168.254.254 = default)
X3! = Subnet mask
nnn.nnn.nnn.nnn (255.255.0.0 = default)
X3@ = Gateway address
nnn.nnn.nnn.nnn (0.0.0.0 = default)
X3# = MAC address
00-05-A6-xx-xx-xx
X3$ = Open connections
0-<maximum number of open connections>
X3% = Port timeout
1 to 65000 in 10-second intervals (30 = default).
