SSP 200 • SIS Configuration and Control 79
Description Response
(Device to Host)
Unsolicited Responses
Audio Input
AudX4@]
Audio input source change
Inf33SrcFormat•X4%•Sampling•X4^•EnChan•X4&]
Volume level
VolX10(]
Input listening mode
SspLX4@*X9*]
Analog level adjustment
SspAX11!]
Analog input clip status
Sts3*X11@]
Current device EXP connection status
ExppRX4!]
EXP input assignment
SspEX4#]
KEY:
X4!
=
Connection Status: 1 = Connected 2 = Not Connected.
X4@
=
Input number: 1 to 5.
X4#
=
EXP assignment (HDMI and analog inputs are unavailable for EXP assignment):
0 = EXP off (default) 2 = Input 2 3 = Input 3 4 = Input 4.
X4%
=
Source format:
0 = Not present 1 = Analog 2 = PCM 3 = Dolby Digital 4 = Dolby Digital Plus
5 = Dolby Digital Plus ATMOS 6 = Dolby TrueHD 7 = Dolby TrueHD ATMOS 8 = DTS or DTS 96/24
9 = DTS‑ES (96/24, Matrix, or Discrete) 10 = DTS‑HD High Resolution Audio 11 = DTS‑HD Master Audio
12 = DTS Express 13 = DTS:X
X4^
=
Decoded Sampling Rate:
0 = None 1 = 32 kHz 2 = 44.1 kHz 3 = 48 kHz 4 = 88.2 kHz
5 = 96 kHz 6 = 176.4 kHz 7 = 192 kHz
X4&
= Source Encoded Channels (Front, Center, Surround, Back, Subwoofer, Height):
0 = None 1 = 1.0 2 = 1.1 3 = 2.0 4 = 2.1 5 = 3.0 6 = 3.1 7 = 4.0
8 = 4.1 9 = 5.0 10 = 5.1 11 = 6.0 12 = 6.1 13 = 7.0 14 = 7.1
X9*
= Listening mode: 1 = Auto (follow source) 2 = Stereo 3 = Mono 4 = Stereo to all 5 = Mono to all
6 = Dolby Surround (Upmixer) 7 = DTS Neural: X (Upmixer)
X10(
=
Volume level: 0 to 100 (0% to 100%)
X11!
=
Analog input gain: -18 to +24 dB
X11@
= Clip status: 0 = Off (no clipping) 1 = On (clipping)
