BEISSBARTH MT 870 / MT 880
4-6
For all motorcycle wheels from 2" rim width with a center hole from 14 mm to 25 mm (with special
accessories also for 10 and 12 mm center holes).
12. Centering the wheel with centering sleeves or centering
cones and fastening with knurled nut.
The two sprung driving pins tighten and drive the wheel from the
outside by means of the tread contact surface.
Insert the appropriate centering sleeve into the wheel hub and
push it on to the center shaft. Make sure that the wheel does not
contact the driving plate but the centering sleeve flange; if neces-
sary, place one of the spacing tubes in between. Place the second
centering sleeve over the center shaft into the wheel hub and
fasten the wheel with the large knurled nut. For special wheel
hubs use the two centering cones instead of the centering sleeves.
(see Fig. 11).
Fig.11
