 Installation manual
CNC 8035
4.
MACHINE PARAMETERS
Spindle parameters
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·144·
4.4 Spindle parameters
SPDLTYPE (P0)
Indicates the type of spindle output being used.
DFORMAT (P1)
Indicates the display format for the spindle.
MAXGEAR1 (P2) MAXGEAR2 (P3) MAXGEAR3 (P4)
MAXGEAR4 (P5)
They indicate the maximum spindle speed assigned to each gear. When using an automatic gear
change, these values will be used to make the change.
MAXGEAR1 for gear 1 (M41).
MAXGEAR2 for gear 2 (M42).
MAXGEAR3 for gear 3 (M43).
MAXGEAR4 for gear 4 (M44).
When not using all 4 gears, use the lower ones and set the unused ones to the same value as the
highest one used.
AUTOGEAR (P6)
Indicates whether the gear change is generated automatically or not by the CNC activating the M
functions M41, M42, M43 and M44.
Value Meaning
0 ±10 V analog output.
1 2-digit BCD coded "S" output. See "2-digit BCD code output conversion
table" on page 447.
2 8-digit BCD coded "S" output.
Default value: 0
Value Meaning
0 In 4 digits.
1 In 5 digits.
2 In 4.3 format
3 In 5.3 format
4 It is not displayed.
Default value: 0
Possible values
Integers between 0 and 65535 rpm.
Default value: For MAXGEAR1 (P2) = 1000 rpm.
For MAXGEAR2 (P3) = 2000 rpm.
For MAXGEAR3 (P4) = 3000 rpm.
For MAXGEARa4 (P5) = 4000 rpm.
Value Meaning
NO There is no automatic gear change.
YES There is automatic gear change.
Default value: NO
