 Installation manual
CNC 8035
HEAT DISSIPATION
Heat dissipation by forced convection with inside fan
2.
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·59·
2.2 Heat dissipation by forced convection with inside fan
Fan whose air flow is Q = 13.6 m
3
/h facing down.
Fan whose air flow is Q = 13.6 m
3
/h facing up.
Fan whose air flow is Q = 30 m
3
/h facing down.
Fan whose air flow is Q = 102 m
3
/h facing down.
Surface without paint.
Surface with smooth metallic enamel.
A
P
5,6 T
------------------=
A
P
7,6 T
------------------=
Ti
Ta
A
P
Surface without paint.
A
P
5,8 T
------------------=
Ti
Ta
A
P
Surface without paint.
Surface with smooth metallic enamel.
A
P
6,75 T
--------------------=
A
P
9,1 T
------------------=
Ti
Ta
A
P
Surface without paint.
Surface with smooth metallic enamel.
A
P
7,5 T
------------------=
A
P
9,8 T
------------------=
Ti
Ta
A
P
