Installation manual
CNC 8035
AXES CONTROLLED FROM THE PLC
Action CNCEX1
12.
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·407·
12.2 Action CNCEX1
The CNCEX1 action is executed via main channel of the CNC and as long as the JOG keyboard
is enabled. Its execution can be interrupted by pressing [CYCLE STOP] or even canceled by
pressing [RESET].
If a CNCEX1 action is received when the JOG keyboard is disabled, the CNC ignores this command.
The block to be executed must be written in the programming format of the CNC itself.
Any type of block can be sent which is edited in ISO or high level language. It admits preparatory
functions, auxiliary functions, calls to subroutines, etc.
