Installation manual
CNC 8035
MACHINE AND POWER CONNECTION
Analog inputs and outputs
3.
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·65·
3.2 Analog inputs and outputs
Analog outputs
They may be used with axis and spindle drives. The electrical characteristics of these outputs are:
Shielded cables should be used connecting the shield at each connector as shown here. See
chapter "1 CNC configuration".
Command voltage within range ± 10 V.
Minimum impedance of the connected drive: 10 Kw.
Maximum cable length without shield: 75 mm.
It is recommended to adjust the servo drives so the maximum feedrate (G00) is
obtained at a velocity command of +9.5V .
