Installation manual
CNC 8035
MACHINE PARAMETERS
General machine parameters
4.
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·79·
INCHES (P8)
It defines the measuring units assumed by the CNC for machine parameters, tool tables and
programming on power-up and after executing M02,M30, EMERGENCY or RESET. The code is:
IMOVE (P9)
Indicates which function G00 (rapid traverse) or G01 (linear interpolation) is assumed on power-
up, after executing M02,M30, EMERGENCY or RESET. The code is:
ICORNER (P10)
Indicates which function, G05 (round corner) or G07 (square corner) is assumed on power-up, after
executing M02,M30, EMERGENCY or RESET. The code is:
IPLANE (P11)
Indicates which function: G17 (XY plane) or G18 (ZX plane) is assumed on power-up, after executing
M02,M30, EMERGENCY or RESET. The code is:
ILCOMP (P12)
It is only used in the Mill model CNC and indicates which function: G43 (tool length compensation
ON) or G44 (tool length compensation OFF) is assumed on power-up, after executing M02,M30,
EMERGENCY or RESET; the code is:
Value Meaning
0 Millimeters (G71)
1 Inches (G70)
By default: 0
Value Meaning
0 G00 (rapid traverse).
1 G01 (linear interpolation).
Default value: 0
Value Meaning
0 G07 (square corner).
1 G05 (round corner).
Default value: 0
Value Meaning
0 G17 (XY plane).
1 G18 (ZX plane).
Default value: 0 (for the M model)
Default value: 1 (for the T model)
Value Meaning
0 G44 (tool length compensation ON).
1 G43 (tool length compensation ON).
Default value: 0
