MAIN PARTS
CONTROLS (“ENDURO” VERSION)
Pos. Description
1 Horn button
2 Beam diverter
3 Stop engine switch
4 Cold start device or choke
5 Clutch control lever
6 Fuel fi ller cap
7 Fuel tank
8 Engine idling speed adjusting
screw
9 Auto-Mixer oil reservoir fi ller cap
10 Auto-Mixer oil reservoir
11 Air fi lter
12 Steering lock
13 Spark plug
14 Gear lever
15 Fuel tap
16
Left footrest
17 Side stand
18 Chain
19 Horn
