98
ENGLISH
To work more comfortably the headlamp may
be detached by loosening the two side screws.
- Shift the complete lamp bracket to the side.
NOTE: handle the plastic parts with care; do not
scratch or damage them.
POSITION LIGHT BULB
Do not tug on the electric cables to take out the
lamp-holder.
- Grasp the lamp-holder and pull it out of its
seat.
- Take out the position light bulb (1) and replace
it with one of the same type.
DIPPED/FULL BEAM BULB
- Do not tug on the electric cables to remove the
bulb electric connector.
- Remove the black rubber sleeve from the central
lamp-holder.
- Release the lamp-holder retaining spring (3) and
remove it.
- Draw out the lamp-holder (2) from the parabola
seat.
- Press the bulb gently and turn it counter clock-
wise.
- Take out the bulb from its seat.
Once the bulb has been changed, just proceed with
the disassembly stages in the reverse order in or-
der to remount the optical unit.
