Faraday MPC-1500 Plus - Page 105

446983 ISSUE I REV. C PAGE 2 OF 2
The following table shows the dip switch settings for proper addressing of the 12506 remotes.
Address Switch 1 Switch 2 Switch 3 Switch 4
1 On On On On
2 Off On On On
3 On Off On On
4 Off Off On On
5 On On Off On
6 Off On Off On
7 On Off Off On
8 Off Off Off On
9 On On On Off
10 Off On On Off
11 On Off On Off
12 Off Off On Off
13 On On Off Off
14 Off On Off Off
15 On Off Off Off
16 Off Off Off Off
SW-9
OFF ON
1
2
3
4
