12530/12540 OWNER'S MANUAL
P/N 447203 Issue I X-1
X. APPENDIX-C: TROUBLESHOOTING
TROUBLESHOOTING INDICATORS
Indicator Location Description
DS1 Main Termination Board City Tie - Indicates open circuit or local energy box needs reset.
DS2 Main Termination Board Monitor - Indicates auxiliary power supply monitor circuit open.
DS3 Main Termination Board Positive Ground - Indicates grounded circuit condition.
DS4 Main Termination Board Negative Ground - Indicates grounded circuit condition.
DS5 Main Termination Board Battery - Indicates open or low battery or blown fuse (F8).
DS7 Main Logic Board Reset - Indicates processor reset in progress.
DEFINITIONS FOR EVENT HISTORY ENTRIES
A. General
ENTRY INDICATES
ALARM General alarm
ALRM Alarm
AVCntr Alarm Verify counter
Blank Plain alarm
CrossZone cross zone point
CZ1A Cross zone
CZ1B Cross zone
CZ2A Cross zone
CZ2B Cross zone
DETECTOR General alarm
HEAT Thermal sensor
ION Ion sensor
LCDxx LCD Annunciator xx
MAIN Main panel
MANL PULL Manual pull station
Mntc Sensor maintenance alert
PAS Positive alarm sequence
PAS INHBT PAS inhibit switch
PHOTO PE sensor
PRE SIGNL pre-signal
PreA Pre-alarm
SUPERVSRY Supervisory
SUPR Supervisory
TRBL Trouble
TROUBLE Trouble
USERx User-defined input x
WATERFLOW Waterflow
