12530/12540 OWNER'S MANUAL
P/N 447203 Issue I X-2
B. System Troubles
ENTRY INDICATES
AC Trouble AC input low or off
AddrLp l DBLSHT Double short trouble on addressable loop l
AddrLp l OPEN Open circuit trouble on addressable loop l
AddrLp l SHORT Short circuit trouble on addressable loop l
AUX POWER Trb Auxiliary power monitor input trouble
AXLP Bad Msg Main processor to loop processor communication trouble
AXLP Fifo Xmit Main processor to loop processor communication trouble
AXLP NoRespons Main processor to loop processor communication trouble
BATT Trouble Battery input low or off
CITY Trouble Local Energy circuit open
CM1aa NoRespons Programmed control module not responding on loop 1 at address aa
CM1aa DataError More than one device responding on loop 1 at address aa
CM1aa OPEN Control module NAC wiring open on loop 1 at address aa
CM1aa SHORT Control module NAC wiring shorted on loop 1 at address aa
DACT Trouble DACT trouble
DACT Acct Trb DACT account reporting trouble
DACT Com Trouble DACT communication trouble with main processor
DACT PL x Trouble Open or short on DACT phone line x
FLASH FATAL Trb Configuration Flash memory trouble
GRND FAULT Trb Ground Fault trouble
IDCxx Trouble IDC xx wiring is open
LCDxx NoRespons LCD Annunciator xx programmed but is not responding
LCDxx Not Pgmd LCD Annunciator xx is not programmed but is responding
LCDxx Trouble LCD Annunciator xx reports trouble
MD100 Addr=00 Module on loop 1 responded to address 00
MD1aa Not Pgmd Module responding is not programmed on loop 1 address aa
MM1aa NoRespons Programmed monitor module not responding
MM1aa DataError More than one device responding on loop 1 at address aa
MM1aa Bad PWs Module responses are not valid on loop 1 address aa
MM1aa Bad Pgm Module responding is not the type programmed on loop 1 address aa
MM1aa OPEN Module IDC wiring open on loop 1 address aa
MNLP Bad Msg Main processor to loop processor communication trouble
MNLP Fifo Xmit Main processor to loop processor communication trouble
MNLP NoRespons Main processor to loop processor communication trouble
NACxx Trouble NAC xx wiring is open or shorted
PC Pgmr Trb Control unit is not receiving communication from PC
Printer Error Printer is off-line or out of paper
QuickTest Abort Quick Test Timer expired causing abnormal exit of Quick Test
SNl00 Addr=00 Sensor on loop l responded to address 00
SNlaa DataError More than one sensor responding on loop l at address aa
SNlaa NoRespons Programmed sensor not responding on loop l address aa
SNlaa Bad PWs Sensor responses are not valid on loop l address aa
SNlaa Tst Flt Sensor is not entering or exiting test mode on loop l address aa
SNlaa Bad Pgm Sensor responding is not the type programmed on loop l address aa
SNlaa TRBL Sensor needs maintenance on loop l address aa
SNlaa Not Pgmd Sensor responding is not programmed on loop l address aa
SNlaa MaintAlrt Sensor needs cleaning on loop l address aa
SNlaa TestValue Not receiving valid sensor test reading on loop l address aa
Trb Reminder Trouble Reminder timer expired
