Faraday MPC-1500 Plus - Main Logic Board Jumpers; Loop Driver Board Jumpers; Conventional Expansion Board Jumpers

12530/12540 OWNER'S MANUAL
P/N 447203 Issue I VI-2
WJ1 & WJ2 – NAC 3 & 4 External Power Input (cut both jumpers if auxiliary power supply is used)
WJ1
WJ2
MAIN LOGIC BOARD JUMPERS
Factory setting is shown.
P3 – NAC A Degraded Alarm Setting
• DEGRD A
•
• Disable
P4 – NAC B Degraded Alarm Setting
• DEGRD B
•
• Disable
LOOP DRIVER BOARD JUMPERS
Device Type Setting (Factory setting is shown.)
J1 J2 J3 J4 J5
F • • • • •
• • • • •
S • • • • •
NOTE: If the control unit has two Loop Driver Boards, both must be set to the same Device Type Setting.
CONVENTIONAL EXPANSION BOARD JUMPERS
WJ1 & WJ2 – NAC 3 & 4 External Power Input (cut both jumpers if auxiliary power supply is used)
WJ1
WJ2
