12530/12540 OWNER'S MANUAL
P/N 447203 Issue I VIII-3
BATTERY SIZE CALCULATIONS
Standby Current (A.) Alarm Current (A.)
12530/12540 Control Unit 0.260 0.400
12522 Loop Driver Standby 0.017 0.017 + NA
Board Alarm 0.022 0.022 NA +
12503 Conventional Standby 0.008 X = + NA
Expansion Board Alarm 0.008 X = NA +
12504 Class A Standby 0.000 0.000 NA NA
Adapter Alarm 0.100 X = NA +
12505 Loop/Signal Standby 0.038 0.038 + NA
Expansion Alarm 0.054 0.054 NA +
12506 Remote Standby 0.020 X = + NA
Annunciator Alarm 0.030 X = NA +
12507 Serial Standby 0.010 X = + NA
Relay Unit Alarm 0.170 X = NA +
12508 Serial Standby 0.000 X = + NA
Relay Extender Alarm 0.160 X = NA +
12509 Serial Standby 0.015 X = + NA
Annunciator Unit Alarm (note 4) 0.040 X = NA +
12510 Serial Annun- Standby 0.005 X = + NA
ciator Extender Alarm (note 4) 0.000 X = NA +
12511 Serial Standby 0.038 0.038 + NA
Isolation Board Alarm 0.038 0.038 NA +
12513 DACT Standby 0.038 0.038 + NA
Expansion Module Alarm 0.054 0.054 NA +
12523 Network Standby 0.085 0.085 + NA
Interface Board Alarm 0.085 0.085 NA +
12526 Iso. Network Standby 0.093 0.093 + NA
Interface Board Alarm 0.093 0.093 NA +
12401A Class A Standby 0.002 0.002 + NA
Adapter Alarm 0.030 X = NA +
12402 Alarm Relay Standby 0.000 0.000 NA NA
Board Alarm 0.037 0.037 NA +
15128 Digital Standby 0.070 0.070 + NA
Communicator Alarm 0.180 0.180 NA +
Addressable Devices
Catalog # Quantity X Current (A.)
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
2-wire Smoke Detectors
Catalog # Quantity X Current (A.)
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
