12530/12540 OWNER'S MANUAL
P/N 447203 Issue I IX-10
Faraday
Catalog
Number
Description Audible
Voltage
(Volts)
Audible
Current
(Amps)
Strobe
Voltage
(Volts)
Strobe
Current
(Amps)
6304-R(*2) Mini-Horn w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.088
6304-T(*2) Mini-Horn w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.154
6304-Y(*2) Mini-Horn w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.170
6304-Z(*2) Mini-Horn w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.249
6310 Mini-Horn-S/T 20-31 DC 0.025
6311 Mini-Horn-S/T 20-31 DC 0.025
6314-E Mini-Horn-S/T w/Strobe 20-31 DC 0.025 20-31 DC 0.059
6314-G Mini-Horn-S/T w/Strobe 20-31 DC 0.025 20-31 DC 0.089
6314-J Mini-Horn-S/T w/Strobe 20-31 DC 0.025 20-31 DC 0.155
6314-K Mini-Horn w/Strobe 20-31 DC 0.025 20-31 DC 0.164
6314-L Mini-Horn-S/T w/Strobe 20-31 DC 0.025 20-31 DC 0.249
6314-M(*2) Mini-Horn-S/T w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.059
6314-R(*2) Mini-Horn-S/T w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.088
6314-T(*2) Mini-Horn-S/T w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.154
6314-Y(*2) Mini-Horn-S/T w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.170
6314-Z(*2) Mini-Horn-S/T w/Sync Strobe 20-31 DC 0.025 20-31 DC 0.249
6320(*2) Sync Electronic Horn 20-31 DC 0.030
6321(*2) Sync Electronic Horn 20-31 DC 0.030
6380 Electronic Signal-8T 20-31 DC 0.024-0.050 (*4)
6381 Electronic Signal-8T 20-31 DC 0.024-0.050 (*4)
Key:
(*1) 1=10” gong, 4=4” gong, 5=chime, 6=6” gong, 8=8” gong
(*2) Sync Strobe Light or Sync Electronic Horn require 5405 or 5406 Sync Control Module
(*3) Sync Electronic Horn and Sync Strobe Light require 5405 or 5406 Sync Control Module
(*4) See Installation Instructions for the current of the desired tone.
Cat. No. xxxx-E = Strobe Light (UL1971 15/75cd) Cat. No. xxxx-M = Sync Strobe Light (UL1971 15/75cd)
Cat. No. xxxx-G = Strobe Light (UL1971 30/75cd) Cat. No. xxxx-R = Sync Strobe Light (UL1971 30/75cd)
Cat. No. xxxx-J = Strobe Light (UL1971 60/75cd) Cat. No. xxxx-T = Sync Strobe Light (UL1971 60/75cd)
Cat. No. xxxx-K = Strobe Light (UL1971 75cd) Cat. No. xxxx-Y = Sync Strobe Light (UL1971 75cd)
Cat. No. xxxx-L = Strobe Light (UL1971 110cd) Cat. No. xxxx-Z = Sync Strobe Light (UL1971 110cd)
Accessory Devices
Faraday
Cat. No.
Mfg. Part Number Description
Faraday, LLC
R711-1 711-1 Polarized Auxiliary Relay
MEP-100 15050 Mini-Evac Control Unit
RSE-100 15070 Remote Signal Expander
15222A 15222A Signal Expander Panel
MVP-500 15060 Mini-Voice Control Unit
MVP-501 15061 Mini-Voice Control Unit
Notes:
1. The accessory devices listed above may be wired to activate from the notification appliance
circuits.
2. For specific wiring and installation information, read the instructions provided with each device.
