12530/12540 OWNER'S MANUAL
P/N 447203 Issue I IX-5
UL Compatible Two-Wire (Circuit Powered) Smoke & Heat Detectors
Zone Identifier – H for 12503 Conventional Expansion Board
Faraday
Detector
w/Base
Mfg.
Detector
w/Base
Number of
Detectors
Per Circuit
Maximum
Standby
Current
Detector
Identifier
Base
Identifier
Air Products & Controls
9267 RW-2W-N 0-30 0.081mA RW-2WN 45681-200
9268 RW-2W-P 0-27 0.110mA RW-2WP 45681-200
Apollo Fire Detectors
9260 w/9262 55000-350 w/45681-220 0-27 0.110mA 55000-350 45681-220
9260 w/9265 55000-350 w/45681-230 0-23 0.130mA 55000-350 45681-230
9261 w/9262 55000-250 w/45681-220 0-30 0.081mA 55000-250 45681-220
9261 w/9265 55000-250 w/45681-230 0-30 0.100mA 55000-250 45681-230
9264 w/9262 55000-153 w/45681-220 0-30 0.057mA 55000-153 45681-220
9264 w/9265 55000-153 w/45681-230 0-30 0.057mA 55000-153 45681-230
9274 w/9262 55000-152 w/45681-220 0-30 0.057mA 55000-152 45681-220
9274 w/9265 55000-152 w/45681-230 0-30 0.089mA 55000-152 45681-230
Faraday, LLC
8842 w/8853 8842 w/8853 0-27 0.110mA 8842 8853
8842 w/8853 (5)
8842 w/8853 (5)
0-13 0.220mA 8842 8853
8843 w/8853 8843 w/8853 0-27 0.110mA 8843 8853
8843 w/8853 (5)
8843 w/8853 (5)
0-13 0.220mA 8843 8853
8854 w/8853 8854 w/8853 0-27 0.110mA 8854 8853
8854 w/8853 (5)
8854 w/8853 (5)
0-13 0.220mA 8854 8853
8854 w/8840 8854 w/8840 0-27 0.110mA 8854 8840
8854 w/8840 (5)
8854 w/8840 (5)
0-13 0.220mA 8854 8840
System Sensor
9184 w/9185 1151 w/B110LP 0-25 0.120mA A A
9183 w/9185 2151 w/B110LP 0-25 0.120mA A A
8434 2100S 0-25 0.120mA A ---
8415 2100TS 0-25 0.120mA A ---
8423 DH100P 0-25 0.120mA A ---
9374 1400 0-25 0.120mA A ---
9375 2400 0-25 0.120mA A ---
9376 2400TH 0-25 0.120mA A ---
9358 w/9361 1451 w/B401B 0-25 0.120mA A A
9358 w/9364 1451 w/B401 0-25 0.110mA A A
9359 w/9361 2451 w/B401B 0-25 0.120mA A A
9359 w/9364 2451 w/B401 0-25 0.120mA A A
9360 w/9361 2451TH w/B401B 0-25 0.120mA A A
9360 w/9364 2451TH w/B401 0-25 0.120mA A A
9447 w/9361 5451 w/B401B 0-25 0.120mA A A
9447 w/9364 5451 w/B401 0-25 0.120mA A A
9176 DH400I (1451DH w/DH400) 0-25 0.120mA A A
9177 DH400P (2451 w/DH400) 0-25 0.120mA A A
Notes:
1. These detector models may be mixed and matched as long as the total maximum standby current
does not exceed 3.0 mA per initiating device circuit. The total number of detectors on a circuit
should not exceed 30.
2. This control unit is not intended to handle more than one 2-wire detector in alarm, per circuit.
3. The activation of a manual pull station or any other contact device, will prevent any 2-wire
detector on the same circuit from remaining activated or activating.
4. If the smoke detector has an alarm verify function, the circuit must not be programmed for alarm
verify.
5. When these detectors are used with 8844 or 8848 Remote LED, the standby current is doubled.
6. For specific wiring and installation information, read the instructions provided with each device.
