VI. PROGRAMMING THE CONTROL UNIT
MAIN TERMINATION BOARD JUMPERS
Factory setting is shown.
P12 – Processor Failure Relay Contact Type
• DGRDO (Open – Form A)
•
• DGRDC (Closed – Form B
P13 – External Power Monitor
• On = Disabled
• Off = Enabled
P50 – Addressable Device Circuit #1 Wiring Style
• Style 4
•
• Style 6/7
P51 – Addressable Device Circuit #2 Wiring Style
• Style 4
•
• Style 6/7
P52 – Reverse Polarity Supervision
• Remote
•
• Local
City Tie Selection Jumper Plug (Move the jumper plug to the desired type of city tie)
JP1 - Reverse Polarity
JP2 – Local Energy
JP3 – Shunt
