446066 ISSUE I Rev. C PAGE 6 OF 6
Catalog
Number
Description Audible
Voltage
Audible
Current
Strobe
Voltage
Strobe
Current
6258-Z (*2) Horn w/Sync Strobe 21-30VDC 0.065A 20-31VDC 0.249A
6300 Mini-Horn 20-31VDC 0.025A
6301 Mini-Horn 20-31VDC 0.025A
6304-E Mini-Horn w/Strobe 20-31VDC 0.025A 20-31VDC 0.059A
6304-G Mini-Horn w/Strobe 20-31VDC 0.025A 20-31VDC 0.089A
6304-J Mini-Horn w/Strobe 20-31VDC 0.025A 20-31VDC 0.155A
6304-K Mini-Horn w/Strobe 20-31VDC 0.025A 20-31VDC 0.164A
6304-L Mini-Horn w/Strobe 20-31VDC 0.025A 20-31VDC 0.249A
6304-M (*2) Mini-Horn w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.059A
6304-R (*2) Mini-Horn w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.088A
6304-T (*2) Mini-Horn w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.154A
6304-Y (*2) Mini-Horn w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.170A
6304-Z (*2) Mini-Horn w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.249A
6310 Mini-Horn-S/T 20-31VDC 0.025A
6311 Mini-Horn-S/T 20-31VDC 0.025A
6314-E Mini-Horn-S/T w/Strobe 20-31VDC 0.025A 20-31VDC 0.059A
6314-G Mini-Horn-S/T w/Strobe 20-31VDC 0.025A 20-31VDC 0.089A
6314-J Mini-Horn-S/T w/Strobe 20-31VDC 0.025A 20-31VDC 0.155A
6314-K Mini-Horn-S/T w/Strobe 20-31VDC 0.025A 20-31VDC 0.164A
6314-L Mini-Horn-S/T w/Strobe 20-31VDC 0.025A 20-31VDC 0.230A
6314-M (*2) Mini-Horn-S/T w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.059A
6314-R (*2) Mini-Horn-S/T w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.088A
6314-T (*2) Mini-Horn-S/T w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.154A
6314-Y (*2) Mini-Horn-S/T w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.170A
6314-Z (*2) Mini-Horn-S/T w/Sync Strobe 20-31VDC 0.025A 20-31VDC 0.249A
6320 (*2) Sync Electronic Horn 20-31VDC 0.030A
6321 (*2) Sync Electronic Horn 20-31VDC 0.030A
6380 Electronic Signal-8T 20-31VDC 0.024-0.050A (*4)
6381 Electronic Signal-8T 20-31VDC 0.024-0.050A (*4)
Key:
(*1) 1=10” gong, 4=4” gong, 5=chime, 6=6” gong, 8=8” gong
(*2) Sync Strobe Light or Sync Electronic Horn require 5405 or 5406 Sync Control Module
(*3) Sync Electronic Horn and Sync Strobe Light require 5405 or 5406 Sync Control Module
(*4) See Installation Instructions for the current of the desired tone.
Cat. No. xxxx-E = Strobe Light (UL1971 15/75cd) Cat. No. xxxx-M = Sync Strobe Light (UL1971 15/75cd)
Cat. No. xxxx-G = Strobe Light (UL1971 30/75cd) Cat. No. xxxx-R = Sync Strobe Light (UL1971 30/75cd)
Cat. No. xxxx-J = Strobe Light (UL1971 60/75cd) Cat. No. xxxx-T = Sync Strobe Light (UL1971 60/75cd)
Cat. No. xxxx-K = Strobe Light (UL1971 75cd) Cat. No. xxxx-Y = Sync Strobe Light (UL1971 75cd)
Cat. No. xxxx-L = Strobe Light (UL1971 110cd) Cat. No. xxxx-Z = Sync Strobe Light (UL1971 110cd)
Compatible Accessory Devices
Order No. Mfg Part Number Description
Faraday
R711-1 711-1 Polarized Auxiliary Relay
MEP-100 15050 Mini-Evac Control Unit
RSE-100 15070 Signal Expander Panel
15222A 15222A Signal Expander Panel
MVP-600 15612 Voice Evacuation Unit
MVP-500 15060 Mini-Voice Control Unit
MVP-501 15061 Mini-Voice Control Unit
Notes:
1. The accessory devices listed above may be
wired to activate from the notification
appliance circuits.
2. For specific wiring and installation information,
read the instructions provided with each
device.
