RESTRICTED USE ONLY Fargo Electronics, Inc.
HDPii High Definition Card Printer/Encoder User Guide (Rev. 1.1)
5-34
Reviewing the Alignment Self Test Card
Step Procedure
1 Use this card to determine Image Placement and confirm that the Printer is
working properly. (Note: The image consists of sixteen (16) gray scale
boxes and alignment arrows. The gray boxes are composed from a
composite of YMC color panels.)
Adjust the TOF and EOF settings to change image placement.
