Process Flow (in table format)
Reviewing the Boot-up Sequence
Step Process
1 The Card feed stepper turns ON (to check for a card in the card path).
2 The Film transfer take-up Motor turns ON to take up any slack in the film.
3 The Print Headlift turns until head up position is returned from Headlift
Sensor.
4 The Print Ribbon moves forward until it finds the yellow panel, pauses,
advances to magenta, then backs up to yellow (the Ribbon Sensor detects
the color of the ribbon).
5 The Transfer Film advances forward two panels from supply (advances until
the Print Film Sensor senses 2 marks on the Film).
6 The Transfer Film advances forward one panel from supply (advances until
the Print Film Sensor senses 1 mark on the Film).
7 The Transfer Film reverses for one panel onto supply (reverses until the Print
Film Sensor senses 1 mark on the Film).
8 The Transfer Film reverses for one panel onto supply (reverses until the Print
Film Sensor senses 1 mark on the Film).
