DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0

November 2013 51

Step

Procedure

Rotate the Lift Bracket (D930136) with the spring (D930266) upwards to disengage the hinge.

Lift out the Pinch Roller Bracket (D930137).

NOTE: Verify orientation when re installing.

Replace with new Platen Roller.

Lock platen with cam first into the front sideplate.
