FARMSCAN Jackal - Tractor Harness Overview; Tractor Harness Diagram and Connections

AM-JACKAL-35/ JULY 2020
6
TRACTOR HARNESS (CONTROL VERSION & SPRAY)
Overview of Tractor Harness as below
Connect to rear of Jackal
Optional GPS Connection for
Ground Speed
12v – To
Battery
Sensor
Connector
Power
Connector to
Sensors
Jackal Tractor
Harness
Part #
AC-4501/T
P2 - GREY
P1 - GREEN
