FS10 Series
Fluid Components International LLC 45
Table 8 – RS232 Interface Reference Table (continued)
Bank Item # Item Name Description R/W Type Size Default
Password
Level
0..9 125 FLOW_K4 "K4" factor applied R/W float 4 0.0 Lev 2
0..9 126 CUST_TEMP_MIN Customer Temperature final
Min. limit
R/W float 4 0.0 Lev 2
0..9 127 CUST_TEMP_MAX Customer Temperature final
Max. limit
R/W float 4 0.0 Lev 2
220 FLOW_COUNT_RAW Raw ADC Counts for Flow Sampling R int 2 N/A N/A
221 REF_COUNT_RAW Raw ADC Counts for REFERENCE
Sampling
R int 2 N/A N/A
222 FLOW_COUNT_ADJ Temp. Compensated Flow ADC Counts R float 4 N/A N/A
223 FLOW_COUNT_FILT Adjusted, filtered Flow ADC Counts R float 4 N/A N/A
224 REF_COUNT_FILT Adjusted, filtered Ref ADC Counts R float 4 N/A N/A
225 dR_OHM Delta R in milliohm R float 4 N/A N/A
226 REF_OHM Reference R in milliohm R float 4 N/A N/A
227 dR_OHM_NORM Normalized dR milliohm R float 4 N/A N/A
228 refR_OHM_NORM Normalized refR milliohm R float 4 N/A N/A
229 dR_OHM_PCED Power Corrected dR in milliohm R float 4 N/A N/A
230 dR_OHM_TCED Temp Compensated dR in
milliohm
R float 4 N/A N/A
231 FLOW_FINAL Temp Comp_ed and N-L
Corrected Flow [FPS]
R float 4 N/A N/A
232 FLOW_FINAL_OUT
FLOW_FINAL used for analog output
(adjusted for customer limits)
R float 4 N/A N/A
233 FLOW_FINAL_UNITS FLOW_FINAL_OUT adjusted by
UNITS_K
R float 4 N/A N/A
234 A_OUT_DAC_COUNT Analog Output DAC Count R int 2 N/A N/A
235 DISPLAY_COUNT COUNT to Be Displayed on LED Bar
Graph
R int 1 N/A N/A
236 DIO_BIT_PATTERN LED/Button Bit Pattern R int 2 N/A N/A
237 BOARD_TEMP_COUNT Raw ADC Counts for On-Board Temp
Sensor Sampling
R int 2 N/A N/A
238 REF_TEMP Computed Temperature [deg. F; refer to
#49 to change units.]
R float 4 N/A N/A
