FS10 Series
44 Fluid Components International LLC
Table 8 – RS232 Interface Reference Table (continued)
Bank Item # Item Name Description R/W Type Size Default
Password
Level
55 QSM2_PERCENT_SPAN Default switch point level as percent of
established span
R/W float 4 30 Lev 2
81 BANK_ID Bank Identification R/W char. 20 Bank ID Lev 2
0..9 107 CUST_FLOW_MIN Customer Flow_Final Limit Min. in SFPS R/W float 4 1.224 Lev 2
0..9 108 CUST_FLOW_MAX Customer Flow_Final Limit Max in SFPS R/W float 4 120.0 Lev 2
0..9 112 RELAY_LIMIT Relay Limit (FPS) R/W float 4 65.0 Lev 2
0..9 113 RELAY_HYSTERESIS Relay Hysteresis =
% of span (#108 [CUST_FLOW_MAX] –
#107 [CUST_FLOW_MIN])
R/W float 4 2.0 Lev 2
0..9 114 RELAY_HYSTERESIS_
EFFECT
Hysteresis either above or below set
point
R/W int 1 1 = above Lev 2
0..9 115 RELAY_POLAR Relay Polarity (1 - Active High,
0 - Active Low)
R/W int 1 1 Lev 2
0..9 116 RELAY_TURN_ON_DELAY Relay Turn-on Delay (secs)
65K secs max. Restricted by #121
value when using buttons
R/W int 1 0 Lev 2
0..9 117 RELAY_TURN_OFF_DELAY Relay Turn-off Delay (secs) 65K secs
max. Restricted by #121 value when
using buttons
R/W int 1 0 Lev 2
0..9 118 DISPLAY_RANGE_MODE Display range either static (0): based on
zero flow and max flow. Or dynamic (1):
based on zero flow, with auto-adjust
(peak hold) for max flow
R/W int 1 0 = static Lev 2
0..9 119 INPUT_FILTER_PERIOD Time constant for input filtering (secs) R/W int 1 3 Lev 2
0..9 120 MAX_HYSTERESIS Maximum hysteresis value for
buttons as % of #112 (switch point)
R/W float 4 10.0 Lev 2
0..9 121 MAX_DELAY Maximum delay for turn on/
turn off delays (sec); effects
button operation only
R/W int 2 10 Lev 2
0..9 122 FLOW_K1 "K1" factor applied R/W float 4 0.0 Lev 2
0..9 123 FLOW_K2 "K2" factor applied R/W float 4 1.0 Lev 2
0..9 124 FLOW_K3 "K3" factor applied R/W float 4 0.0 Lev 2
