Fellowes Proteus A3/125 - Remove;Replace Power Switch

Revised 09.15.11 Proteus A3/125 Technical Service Manual
20
6 Push the new Socket into the panel. The tabs lock into
position when properly in place.
7 Replace power and grounding wires.
Remove/Replace the Power Switch
1 Press down on 2 locking tabs on the Power Switch and
push the Switch out.
2 Push the new Switch into the panel. The tabs lock into
position when properly in place.
3 Push the Cord Socket with Switch into the panel. The
tabs lock into position when properly in place.
4 Reconnect power and grounding wires.
DO THIS FIRST
Remove Housing Cover
TOOLS
Long nose pliers
Philips screwdriver
