ferrotec Temescal CV-6SLX User Manual

2.6 Cable Installation Section 2: Installation
CV-6SLX User Manual 0101-8242-0, Rev. C
2-16
Figure 2-16 System I/Os Exchanged via FPS Front Panel Connector J101
and the FPS I/O Cable (PN 0620-6672-2)
NOTE: DEPOSITION CONTROLLER INPUT
On the CV-6SLX power supply, the polarity of the emission current request input (J101 Pin 10) must be
positive. Reversal of this input’s polarity may result in damage to the power supply.

ferrotec Temescal CV-6SLX Specifications

General

Brand	ferrotec
Model	Temescal CV-6SLX
Category	Power Supply
Language	English
