Section 3: Power Supply Operation 3.5 Control of Power Supply from TemEBeam EBC Integrated Controller
0101-8242-0, Rev. C 3-7 CV-6SLX User Manual
Functional Definitions of PS-Related LED Indicators on the Diagnostics Screen
Except where noted, the indicators on this screen are gray (off) when the signal in question is
false and green when it is true.
High Voltage Section
• Interlock LED: Status of the HV interlock input from the HVPS
• HV Ready LED: Status of the HV READY input from the HVPS
• HV is ON LED: Status of the IS ON input from the HVPS
• Fault LED: On systems with CV6-SLX HV power supplies, this LED indicates the status of the
HV FAULT input from the HVPS. It is green when that input is false and red when that signal
is true, indicating that a latching power supply fault has occurred. For additional information
about latching HVPS faults, see section 5.2.
Gun Section
• Is Ready LED: Status of the IS READY input from the FPS
• Is ON LED: Status of the IS ON input from the FPS
• Manual Bias LED: Off (gray) when autobias is selected via the Configuration>E-Beam screen
and green when manual bias is selected.
• Auto Bias LED: Green when autobias is selected via the Configuration>E-Beam screen and
off (gray) when manual bias is selected.
High Voltage/Gun Interlocks Section
The Tank, Vacuum, Auxiliary, Water, and Position LEDs indicate the state of the
corresponding inputs from the HVPS and the FPS, which in turn reflect that state of the external
interlock switches that must be made before the gun or HV can be enabled.
3.5.7 Switching the Beam On/Off and Setting Beam Power from the Remote
Controller
Figure 3-9 shows how to switch the beam on/off and control beam power from the EBC’s hand-
held remote controller.
