6. Electrical installation
Festo.P.BE-CMMS-ST-G2-HW-EN 1008NH 105
1 Main switch
2 Fuse
3 Power pack for
control voltage
4 Power pack for
power supply
5 CMMS-ST
6 PC
7 Motor
Fig. 6.4 Complete structure of CMMS-ST with motor and PC
7
4
1
2
3
5
6
