A. Technical data
132 Festo.P.BE-CMMS-ST-G2-HW-EN 1008NH
A.3.5 Motor connection [X6]
Output data Values
Output current 8 A
eff
Max. output current for 2 s 12 A
eff
Max. output frequency 50 kHz
Table A.15 Technical data: Motor connection data [X6]
Features Values
Voltage range 18 … 30 V
Output current 0.5 A
Voltage loss ≤ 1 V
Short circuit / overcurrent protection > 4 A
Temperature protection T
J
> 150°C
Loads - R > 24 Ω
- L approx. 10 H
- C < 10 nF
Switching delay < 1 ms
Table A.16 Technical data: Holding brake
A.3.6 Power supply [X9]
Features Values
Load supply voltage 48 VDC
Alternative DC supply 24 … 48 VDC
Nominal input current 8 A
Minimum intermediate circuit voltage 12 ... 48 V (configurable)
Control section supply voltage 24 VDC [± 20%]
Control section nominal current 0.2 A
Maximum current (incl. holding brake) 1.5 A
PWM frequency 50 kHz
Table A.17 Technical data: Power data [X9]
Features Values
Internal braking resistor
17 Ω
Pulse power 500 W
Continuous output 10 W
Response threshold 58 / 30 V
