3. Product description
Festo.P.BE-CMMS-ST-G2-HW-EN 1008NH 41
speed and position for EMMS-ST series motors. The actual speed is determined based on
the measured rotor position. The rotor position is smoothed via a configurable PT
1
filter.
The position counter for positioning has a data width of 32 bits. The position within a
motor rotation is resolved to max. 16 bits. This results in a maximum possible positioning
range of ±32767 rotations.
3.3.9 Brake chopper
A brake chopper with a braking resistor is integrated in the power output stage. If the
permitted load capacity of the intermediate circuit is exceeded during the energy
recovery, the braking energy may be converted to heat by the internal braking resistor.
The brake chopper is actuated with software control. The internal braking resistor is
protected against overloading via software and hardware.
Note
If the maximum braking energy of the braking resistor is exceeded,
the message “070 – Overvoltage in intermediate circuit” is output
and the end stages switched off.
3.3.10 Control interface [X1]
The control interface [X1] is designed as D-Sub 25-pin. The following signals are available:
Pin Name Mode 0
(DIN12=0)
Mode 1
(DIN12=1)
Mode 2
(DIN9=1 &
DIN12=0)
Mode 3
(DIN9=1 &
DIN12=1)
1 AGND Screen for analogue signals
14 AGND Reference potential for
analogue signals
2 AIN0
DIN12
Setpoint input 0
Mode switchover
"1" "0" "1" slave synch.
15 #AIN0
DIN13
Stop input (low active)
STOP STOP STOP
3 DIN10 Record selection 4
(high active)
Jog + Next 1 -
16 DIN11 Record selection 5
(high active)
Jog - Next 2 -
4 +VREF Reference output for setpoint
potentiometer
17 AMON0 Analogue monitor output 0
5 Unassig
ned
Unassigned Unassigned Unassigned Unassigned
18 + 24 V 24 V supply carried out
