Festo CMMS-ST-C8-7-G2 Assembly And Installation

3. Product description
70 Festo.P.BE-CMMS-ST-G2-HW-EN 1008NH
ENABLE
START/TEACH
STOP
DIN10: Jog +
Drive is moving
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
–
DIN11: Jog -
1
0
– – –+ + –
DOUT0: READY
DOUT1: MC
DOUT2: ACK-TEACH
DOUT3: ERROR
t1 t1tx tx t1 tx t1 t1tx tx
t
1 = 1.6 ms
tx = x ms (dependent on brake ramps)
Fig. 3.11 Signal sequence when both signals are activated simultaneously / briefly
staggered

Festo CMMS-ST-C8-7-G2 Specifications

General

Brand	Festo
Model	CMMS-ST-C8-7-G2
Category	Controller
Language	English
