1. Installation
1-4
Festo P.BE-CPX-FB32-EN en 1111a
Electrical connection and display elements
On the fieldbus node CPX-F B32 you will find the following
connection and display el ements:
1
2
3
4
1
Bus-status-specific and CPX-specific
LEDs
2
Fieldbus interface: Ethernet connection
(4-pin M12 socket, D-coded)
3
Transparent cover fo r the DIL switches
4
Service interface for the Hand-
held (V24)
Fig. 1/1: Connecting and display elements on the CPX fieldbus node
