Festo CPX-FB32 - Page 50

2. Commissioning
2-16
Festo P.BE-CPX-FB32-EN en 1111a
Module
no.
Module Input address Output address
0 Fieldbus node CPX-FB32 with
status bits
I0 ... I15
1)
–
1 Digital 8-input module CPX-8DE I16 ... I23 –
2 Digital 8-input module CPX-8DE I24 ... I31 –
3 Digital 4-output module
CPX-4DA
– O32 ... O39
2)
4 Digital multi I/O module
CPX-8DE-8DA
I32 ... I39 O40 ... O47
5 Analogue 2-o utput module
CPX-2AA
– O0 ... O31
6 VTSA pneumatic interface set with
DILswitchto1...8valvecoils
– O48 ... O55
1)
16 bits occupied, 8 bits used
2)
8 bits occupied, 4 bits used
Tab. 2/10: Addressing the example terminal 3 (see Fig. 2/3)
