1. Installation
1-20
Festo CPX-FB36-EN en 1611a English
1.3.6 Extended network settings
The following settings for the network connection can be
made through the Ethernet link object 0xF6 (246
d
) (èC.2.4).
In the factory setting, the bus node automatically detects the
baud rate and duplex mode.
Baud rate
Setting via attribute 6 (Forced Interface Speed) of the Ether
net link object:
– 10 Mbit/s
– 100 Mbit/s
Duplex mode
Setting via attribute 6 (control bits, bit 1) of the Ethernet link
object:
– Half duplex
– Full duplex
