1.4 Ensuring the degree of protection
Use connection technology with the required degree of
protection (è www.festo.com/catalogue, examples in
Tab. 1/11).
Use cover caps to seal unused connections.
Compressed air Connection technology Cover cap
Network connection (M12) Plug connector NECU-M-S-D12G4-C2-ET ISK-M12
Service interface (M12) Connecting cable KV-M12-M12-...
1)
ISK-M12
1) Connecting cable for the operator unit (CPX-MMI)
Tab. 1/11: Connection technology and cover caps for degree of protection IP65/IP67
(examples)
