Function
The following tables give an overview and a description of the CPX module parameters included in the
CTMM-S1-C.
Function number
1)
Bit Parameter Default
4828 + m × 64 + 0 0 Monitoring short circuit/overload sensor
supply (SCS)
active
2 Monitoring undervoltage outputs/valves
U
OUT
/U
VAL
active
4828 + m × 64 + 6 0 Monitoring negative pressure active
1) m = module number (counting from left to right, beginning with 0)
Tab. 3: Overview of the CPX module parameters
Description of the CPX module parameters
Monitoring short circuit/overload, monitoring undervoltage U
OUT
/U
VAL
Function number 4828 + m × 64 + 0
m = module number (0 … 47)
Description Monitoring the Motion Terminal for the following error:
–
Short circuit or overload in sensor supply
–
Undervoltage at the valves U
VAL
The monitoring of the errors can be individually activated or deactivated.
Active monitoring has the following effect:
–
Error message at the CPX field bus nodes
–
Malfunction message in the VTEM diagnostic memory
Both types of monitoring can also be activated for the entire CPX terminal.
For details, see the manual of the CPX terminal
è
1.1 Applicable documents.
Allocation Bit 0 Monitoring short-circuit or overload of the sensor supply
Bit 1 reserved
Bit 2 Undervoltage monitoring at the valves U
VAL
Bit 3 … 7 reserved
Values Bit 0, 2 0 = inactive
1 = active (default)
Monitoring negative pressure
Function number 4828 + m × 64 + 6
m = module number (0 … 47)
