1. Summary of components
1−8
Festo P.BE−VTSA−44−EN en 0509NH
The VTSA valve terminal with multipin cage clamp consists of
the following electrical components:
1 Cover
2 Multipin node
with cage clamp
1
2
Fig.1/4: Electrical components of the VTSA valve terminal with multipin node cage clamp
The VTSA valve terminal with multipin M23 round plug
consists of the following electrical components:
1 Multipin node
with M23 round
plug
1
Fig.1/5: Electrical components of the VTSA valve terminal with multipin node M23
round plug
