Fibocom SU806 Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 24 of 91
Pin Name
Pin
Number
I/O
Functional Description
Note
ACCL_INT
110
DI
Accelerometer sensor interrupt
-
Other interface
ADC
128
AI
ADC detection
-
LED_B
194
AI
RGB LED input2
-
LED_G
195
AI
RGB LED input1
-
LED_R
196
AI
RGB LED input0
-
CHG_EN
210
AO
Charge enable
The module does not
support charging, and
DC-DC circuit can be
added if charging function
is required.
ADC4_BAT_ID
260
AI
BAT_ID detection
-
NFC_CLK
256
DO
NFC clock
Reserved
NFC_DWL_REQ
257
DI
NFC power reset control
Reserved
GPIO interface
GPIO_134
33
I/O
General Purpose Input and
Output.1.8V power domain
INPUT(WPD)
GPIO_129
90
I/O
INPUT(WPD)
GPIO_135
98
I/O
INPUT(WPU)
GPIO_136
99
I/O
INPUT(WPU)
GPIO_137
100
I/O
INPUT(WPU)
GPIO_131
101
I/O
INPUT(WPD)
GPIO_130
102
I/O
INPUT(WPD)
GPIO_133
103
I/O
INPUT(WPD)
GPIO_132
104
I/O
INPUT(WPD)
GPIO_121
105
I/O
OUTPUT
GPIO_138
106
I/O
INPUT(WPU)
