Pin Name
Pin
Number
I/O
Functional Description
Note
GPIO_91
108
I/O
INPUT(WPD)
GPIO_32
112
I/O
INPUT(WPD)
GPIO_89
113
I/O
OUTPUT
GPIO_122
115
I/O
WPD
GPIO_139
123
I/O
INPUT(WPU)
GPIO_140
124
I/O
INPUT(WPU)
GPIO_88
153
I/O
INPUT(WPU)
GPIO_30
159
I/O
INPUT(WPD)
GPIO_29
183
I/O
INPUT(WPD)
GPIO_27
187
I/O
INPUT(WPD)
GPIO_85
202
I/O
OUTPUT
GPIO_154
203
I/O
INPUT(WPD)
GPIO_155
205
I/O
INPUT(WPD)
GPIO_28
206
I/O
INPUT(WPD)
GPIO_24
207
I/O
INPUT(WPD)
Boot configuration
doesn’t add pull-up
GPIO_11
241
I/O
INPUT(WPD)
GPIO_7
242
I/O
INPUT(WPD)
GPIO_143
243
I/O
INPUT(WPU)
GPIO_10
244
I/O
INPUT(WPD)
GPIO_141
97
I/O
INPUT(WPU)
GPIO_26
252
I/O
INPUT(WPD)
GPIO_22
253
O
INPUT(WPD)
GPIO_23
254
I/O
INPUT(WPD)
