APPENDIX C
C-4 Cheetah Xi 50 Installation Manual UL S2203
Rev 6, 09/2015 P/N: 03-369 FM
Exhibit C-4: Compatible Components – Cont.
SPARE PARTS
02-4035 Hardware Kit, #6 lock washers and hex nuts (30 each)
02-10788 Standoff kit, 5/8” M/F, 5 each required for DACT (10 each supplied)
02-4009 Standoff, 2” M/F, for Cheetah Xi 50 controller, 4 each required (1 each supplied)
02-11751 Standoff, 2” F/F, for Cheetah Xi 50 controller, 1 each required (1 each supplied)
02-11823 Key lock with cam
02-4983 Panel Key Only (without cam)
02-10881 Transformer, 120VAC
02-10882 Transformer, 240 VAC
02-4040 Battery, Lithium Coin Cell, 3V
10-2625 Monitor and Control Module EOL Assembly, 39K
10-2530 14KΩ Series Resistor, for Monitor Module Short Circuit detection
10-2570 End of Line Resistor, 1.2 K (for NAC 1 & 2)
02-4174 Fuse, 15 Amp, Mini-Auto, Fast Acting (For F1 & F2) (Little fuse p/n 297015)
02-11412 Fuse, 4 Amp, Mini-Auto, Fast Acting (For F3-5) (Little fuse p/n 297004)
02-4981 End Of Line Relay – System Sensor EOLR-1
02-2519 Termination Resistor, 100 ohm (for RS485 circuit)
02-11723 Bezel, Outer Door
C.1.1 TOUCH-UP PAINT (NOT AVAILABLE FROM FIKE)
Sherwin Williams, Signal Red – RAL 3001 per RAL 840-HR (Matt Finish)
Sherwin Williams, Light Gray – RAL 7035 per RAL 840-HR
C.1.2 NOTIFICATION APPLIANCES
Refer to Fike document 06-186 for compatible notification appliances.
C.1.3 APPROVED RELEASING DEVICES
Refer to Fike document 06-186 for compatible releasing devices.
