Operating the FT-100/CI and FT-170/CI 3-15
Document 40275-0913
3. Continue to push until the case is centered under the unslit
flap sensors.
4. Check that each sensor is aimed at the center of the top
surface of the corresponding flap.
5. Without moving the case, simultaneously press the limits
switches on top of each sensor.
6. When the light emitting diodes (LEDs) begin to flash, wait
five seconds and then press the limit switches again
7. Do the LEDs glow continuously either green or red or
continue to flash?
If yes, the LEDs glow continuously, then stop, as you have
successfully calibrated the sensors.
If no, the LEDs continue to flash, repeat from step 4
.
