36
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
DISCHARGE ASSEMBLY
Ref. No. Part Number Description No. Req’d
35 031338-10 Top Seal Retaining Plate 1
36 031338-09 Top Seal 1
37 031243-08 Elbow Hinge Rod 1
38 031338-11 Hinge Seal 1
39 z Keps Nut, No. 10 - 24 30
40 z Slotted Flat Head Machine Screw, No. 10 - 24 x 0.625 LG. 8
41 z Slotted Round Head Machine Screw, No. 10 - 24 x 0.5 LG. 7
42 z Slotted Round Head Machine Screw, No. 10 - 24 x 0.375 LG. 5
43 z Slotted Flat Head Machine Screw, No. 10 - 24 x 0.5 LG. 10
44 031341 Seal Plate Assembly 1
44A 031338-01 Seal Plate Hinge 1
44B 031238-04 Bottom Seal Plate 1
44C 031338-08 Side Seal 2
44D 031338-07 Side Retaining Plate 2
44E 031338-03 End Flap Seal Retainer 1
44F 031338-04 End Flap Seal 1
45 031240 Discharge Tube 1
46 031338-12 Side Elbow Seal 2
z Standard Hardware Item - Available at your local hardware store.
