67
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
ENGINE PARTS
Ref. Kit
No. Ref. Part Number Description No. Req’d
1 031542 Overflow Bottle Assembly, 1 quart 1
2 z Hose Clamp, 24 - 44 mm 4
3 z Hex Flange Machine Screw, M8 - 16 x 1.25 LG 3
4 031534 Radiator Support, Upper 1
5 031538 Radiator Mount Isolator, Upper 1
6 031544 Upper Radiator Hose 1
7 031504 Yanmar 3TNV88C-DYEM Engine
8 031273 Coupling Flange 1
9 z Hexagonal Socket Set Screw, 5/16 - 18 UNC x 0.7 LG 2
10 z Hex Head Cap Screw, 5/8 - 11 UNC x 3.5 LG 4
11 005861 Washer 4
12 031205-01 Rear Engine Foot 2
13 005860-03 Engine Isolator 4
14 031503-01 Engine Mount Adapter Plate 1
15 z Prevailing Torque Hex Nut, 3/8 All Metal Type 4
16 z Plain Washer, 5/8 Regular Type B 4
17 z Hex Head Cap Screw, 1/2 - 13 UNC x 2.5 LG 2
18 031537 Plain Washer 2
19 031539 Radiator Mount Isolator, Lower 2
20 31501-00 Front Engine Foot Weldment 2
21 z Hex Head Cap Screw, M10 - 25 UNC x 1 LG 2
22 031562 V-Belt, Fan 1
23 031563 Cooling Fan 1
24 031545 Lower Radiator Hose 1
25 031541 Radiator Assembly 1
26 031535 Radiator Mount, Upper 1
27 031536 Radiator Mount Spacer, Upper 2
28 031548 Hose, Air Intake 1
29 031552 Rain Cap Assembly 1
30 031549 Air Cleaner Assembly with Air Filter Element 1
031550 Air Filter Element 1
31 031551 Band, Air Cleaner 1
32 000461 Exhaust Clamp 1
33 031555 Starter 1
34 031488-01 Tailpipe Extension 1
35 031556 Alternator 1
Continued to next page.
