WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CONTROL BOX MOUNT AND LIFT EYE ASSEMBLY
(STANDARD R-H AND SKID MODELS)
Ref. No. Part Number Description No. Req’d
1 z Hex Head Cap Screw, 3/8 - 16 UNC - 1.25 LG. Grade 5 6
2 z Plain Washer, 3/8 Regular Type B 20
3 z Prevailing Torque Hex Nut, 3/8 All Metal Type 8
4 031393-01 Support Arm (left hand side) 1
5 031326-04 Tie Down Pad 1
6 z Hex Head Cap Screw, 3/8 - 16 UNC - 1.75 LG. Grade 5 2
7 z Hex Head Cap Screw, 3/8 - 16 UNC - 3.25 LG. Grade 5 2
8 031326-05 Lift Eye Weldment 1
9 031393-02 Support Arm (right hand side) 1
10 z Prevailing Torque Hex Nut, 1/4 All Metal Type 4
11 z Plain Washer, 1/4 Regular Type B 8
12 z Hex Head Cap Screw, 1/4 - 20 UNC - 1.0 LG. Grade 5 4
13 031515 Control Box Assembly 1
(See Control Box section for parts detail.)
14 031572 Control Box Mount Bracket 1
15 008422 Loop Clamp 1
16 z Helical Spring Lock Washer, 3/8 Regular 2
17 z Hex Nut, 3/8 - 16 2
z Standard Hardware Item - Available at your local hardware store.
To Next Page
