Finn B70 - Clutch Assembly

65
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CLUTCH ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 100333 Clutch Assembly (Includes Key Numbers 2 through 24) 1
2 X Clutch Body 1
3 100209 Facing Plate 1
4 X Pressure Plate 1
5 X Adjusting Ring 1
5A X Wear Plate for Adjusting Ring (not shown) 1
6 100211 Lever Spring 1
7 X Lever 3
8 X Clevis Pin 3
9 X Retaining Ring 3
10 X Lock Bolt 1
11 X Lock Washer 1
12 100214 Adjustment Lock 1
13 X Link 6
14 X Clevis Pin 3
15 X Retaining Ring 3
16 X Clevis Pin 3
17 X Retaining Ring 3
18 X Separator Spring 3
19 X Release Sleeve 1
20 X Bearing Carrier 1
21 X Release Bearing 1
22 X Internal Snapring 1
23 X External Snapring 1
24 X Grease Fitting 1
25 100218 Drive Ring 1
NOT SHOWN
100045 Locking Nut 1
(See Power Take Off Assembly section for reference.)
100047 Locking Washer 1
(See Power Take Off Assembly section for reference.)
NOTE: Items with Part Number listed as "X" are only available as part of assemblies listed.
